ADVANTAGES AT A GLANCE

• Very high cutting speed, fully variable from 500 up to 5000 rpm.

• German BE-Maschinenmesser knives, special high resistance KUT steel.

• Minimum space between all knives and the bowl thanks to its large central diameter.

• Slow mixing speed, variable 50 to 500 rpm, forward and reverse.

• New vibration reduction technology at high revs, collaboration with the UPV Polytechnic University.

• 4 onscreen buttons for direct selection of knife and bowl speeds, freely con gurable.

• Transparent noise protection cover with CE safety clearance of the knife speed when opening and returning to the previous speed when closing.

• Excellent professional results with meat, vegetables, vegan/ vegetarian food, fish, special dough.

STAINLESS STEEL FRAME

• Very robust construction, heavy machine, between 2300 and 2600 kg (K135s).

• Completely stainless: entire frame, external and internal, in AISI304 stainless steel, as well as all possible hardware and components.

• Very solid, 220 kg cast stainless steel bowl, with outer rim to prevent liquids or dough from spilling.

• Low height of bowl, for more comfortable use.

• Adjustable, stainless steel machine feet, non-slip and vibration absorbing.

• Very solid, 220 kg (K135s) cast stainless steel bowl, with outer rim to prevent liquids or dough from spilling.

STANDARD EQUIPMENT

Removable 6-knife head and compensating rings for use with 3.

Interactive recipes, can be stored and executed directly on the machine’s screen.

Control panel with large 15” Schneider Electric digital touch screen, all information displayed simultaneously and in large size.

Transparent noise protection cover with automatic decrease of knife speed.

Motorized stainless-steel knife lid for effortless lifting and lowering.

Completely stainless: entire frame, external and internal, in AISI304 stainless steel, as well as all possible hardware and components.

CUTTING MECHANICS

Large diameter knife shaft, very reliable, with advanced quality bearings and seals for high rpm.

Hygienic labyrinth in knife head to prevent dough from entering the shaft.

Lower cavity of stainless-steel lid with removable separation plate to expand or compress the work-space of the knives.

EASY CLEANING

Removable lid/bowl friction band.

Removable bowl rim scraper.

Bowl with drain plug for liquids.

OPTIONAL EQUIPMENT

PowerPlus: stronger knife motor for heavy applications.

Manual unloader arm with motorized extracting disc, variable speed 70-200 rpm.

Hydraulic bin loader and hydraulic unloader arm with motorized extracting disc, variable speed 70-200 rpm.

ELECTRICS AND ELECTRONICS

Powerful motors to quickly processing of the most compact frozen dough.

Two knife-motor powers available.

Soft start and stop of knifes, bowl and extracting disc (optional) by mean of speed drives.

High energy ef ciency class IE3, high performance ABB motors and last generation drives.

Automatic knife safety stop.

Thermal motor protections.

Fast and sensitive digital thermometer, with sensor extended into the internal cavity of the lid.

Folding internal electric panel, easy access, temperature-controlled cooling system.

Electronic/electric components of rst brands Schneider Electric and ABB.

Folding internal electric panel, easy access, temperature-controlled cooling system.

Fast and sensitive digital thermometer, with sensor extended into the internal cavity of the lid.

Soft start and stop of knifes, bowl and extracting disc (optional) by mean of speed drives.

SOFTWARE AND EXTERNAL CONNECTIONS

• Control panel with large 15” Schneider Electric digital touch screen, all information displayed simultaneously and in large size.

• Extensive information on controls, alarms, errors, diagnostics.

• Very advanced and practical software with numerous automatic stop options. Intuitive, easy to use.

• Interactive recipes, can be stored and executed directly on the machine’s screen.

• New Talsa EcoCut Power Control to determine the machine power required to achieve the desired cutting results at any time of the process.

• Industry 4.0 digital solutions for maintenance, process integration and custom solutions.

• Remote Service and Support access over secure internet connection (router/ethernet or mobile phone).

TECHNICAL SPECIFICATIONS

Important advice: always choose large bowl cutter capacity and power, to allow the future growth of production. Available Talsa capacities: 15, 30, 55, 95, 135 and 200 liters
